ACL bearings are used for tuning and engine upgrades where you want better quality with higher bearing capacity than normal standard bearings.
Improvements of material, dynamic thickness, heat conduction, oil grooves and oil distribution are some of the points that make ACL one of the leading bearing manufacturers.
Bearing data
Part number: 7M8103H
Bearing size: STD
Bearing half type: Upper & lower
Bearing material: F780
Technical data (mm)
Max overall length: 20
Max shaft size: 62.001
Max tunnel size: 66.035
Max vertical oil clearance: 0.059
Max wall at crown: 2.004
Min shaft size: 61.984
Min tunnel size: 66.02
Min vertical oil clearance: 0.068
Technical data (in)
Max overall length: 0.7874
Max shaft size: 2.441
Max tunnel size: 2.5998
Max vertical oil clearance: 0.0023
Max wall at crown: 0.0789
Min shaft size: 2.4403
Min tunnel size: 2.5992
Min vertical oil clearance: 0.00267716
Engine code
1JZ-GE / 1JZ-GTE
Application
Toyota 1JZ-GE 2492cc Inline6 DOHC 4v
Toyota 1JZ-GTE 2492cc Inline6 DOHC 4v Twin Turbo
